SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel

  • SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel
  • SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel
  • SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel
  • SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel
Place of Origin NINGBO, CHINA
Brand Name SUMT, ANT
Certification CE
Model Number 5X5 station
Minimum Order Quantity MOQ:4pcs
Price Negotiable
Packaging Details Box+carton, 15pcs/Carton, 30kg/carton, carton size: 52X51X28cm
Delivery Time 3-20 working days depending on the quantity
Payment Terms T/T, Western Union, MoneyGram,Paypal
Supply Ability 5000-1000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Dumbwaiter COP/LOP/button Calling Box Voltage DC24V
Floor Number Suitable To 4 Floors Application Particuarlly For Goods Lift /dumbwaiter
Display Mode Decimal Code Calling Number 5pcs/each Set, 1 With Lock
High Light

SUMMIT Elevator Push Button Panel LOP

,

Goods Elevator Push Button Panel DC24V

,

DC24V Service Lift Push Button Panel
Leave a Message
Product Description

SUMMIT DC24V DC24V 2 to 6 floors five layer elevator dumbwaiter car calling push button box

Description:

The calling panel is designed particularly used for the goods lift or dumbwaiter, and it is available from 2 floor to six floors



Technical Paramters:

Production name Push button calling box
Working voltage DC24V+/-5% (common cathode)
Display mode Decimal code display
Rated power <2W
Suitable for layer 2-6 layer station
Panel material 304 stainless steel(thickness 2mm)
Bottom box material Galvanized iron sheet
Layer display 1 position digital tube display
Direction display 1PC of up and down arrows
Special display Opening/closing tips
Voice prompt Buzzer
Lay button One button each floor
Scram button 1 piece
Power lock 1pice (2keys)




The Dumbwatier calling box 2*2 station size:

SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 0

SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 1

SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 2SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 3SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 4SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 5SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 6


SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 7

Instruction:

Your trustworthy partner-SUMMIT
With more than 20 years experience in the elevator and lifting industry and with our highly qualified and dedicated staffs, we can provide you the best possible sensor and weight measuring solutions in all types of installations. SUMMIT ensures safety and quality at all steps of elevator and lifting. We at SUMMIT would like to be more close to you, we listen to you, understand your needs and provide the best solution.
- SUMMIT is your trustworthy partner you can rely on.
SUMMIT Elevator Push Button Panel DC24V Goods Service Lift Push Button Panel 8
